DAHUA DH-XVR5108HS-X 08 Channel Penta-brid Digital Video Recorder
Features and Key points :
• DAHUA 08 CH PENTA - BRID DVR (1080P)
• H.265+ video compression
• Support up to 5 MP Camera
• Penta – brid : Support HDCVI/ HDTVI/ AHD Analog & IP Camera
• All Channel @ 1080P Recording
• HDMI & VGA Out Put Up to 1080P
• Support 1 HDD (Up to 10 TB)
• Full Metal Casing
• Installation with expert Technician
• Best price in Bangladesh
• Call for Discount / Price Match policy
Buy DAHUA XVR5108HS-X with best Price in Bangladesh
DAHUA DH-XVR5108HS--X Digital Video Recorder supports HDCVI/AHD/TVI/CVBS/IP video inputs with H.265+/H.265 dual-stream video compression. This 8 Channel penta-brid recorder has maximum 4K resolution with 48Mbps incoming Bandwidth. The storage capacity up to 10TB of 1 SATA Port provides full freedom of usability.
Key Features of DAHUA DH-XVR5108HS-X 08 Channel Penta-brid Digital Video Recorder
- Main Processor: Embedded Processor
- Operating System: Embedded LINUX
- Resolution: 4K, 6MP, 5MP, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, CIF
- Internal HDD: 1 SATA Port, up to 10TB capacity
- Analog Camera Input: 8 Channel, BNC
- IP Camera Input: 8+4 Channel, each channel up to 8MP
- Audio In/Out: 1/1, RCA
- Display Resolution:HDMI:3840×2160, 2560×1440, 1920×1080, 1280×1024,1280×720 / VGA: 1920×1080, 1280×1024, 1280×720
- Display Interface: 1 HDMI, 1 VGA
- Network Interface: 1 RJ-45 Port (1000M)
- Dimensions: 260×236×48mm
- Net Weight: 0.9kg
DAHUA XVR5108HS-X Specification:
|
Model |
XVR5108HS-X |
|
Type |
8 Channel Penta-brid 1080P Compact 1U Digital Video Recorder |
|
Analog Camera Input |
8 Channel, BNC |
|
Recording Compression |
H.265+/H.265/H.264+/H.264 |
|
IP Camera Input |
8+4 Channel, each channel up to 6MP |
|
Display Resolution |
HDMI:1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720 |
|
Network Interface |
1 RJ-45 Port (100M) |
|
Power Supply |
DC12V/2A |
Special Functions
Smart H.265+Smart Codec, H.265+ can reduce up to 90% bit rate and storage requirements compared with H.264 without having to invest in new cameras. HDCVI/AHD/TVI/CVBS/IPAuto-detect The XVR can auto recognize the signal of front-camera without any setting. It makes operation more friendly and convenient. IPC Input SupportedThe XVR1B16 suppports up to 6MP IPC input. Coaxial Audio/Upgrade/AlarmThe integrated design can reduce wiring troubles which makes it much more cost-effective and convenient for installation. |
Long Distance TransmissionThe HDCVI system supports long distance transmission over coaxial cable and UTP, max. 800m for 1080P and 1200m for 720P.Smart SearchThis function helps you get more motion detect video during a short time through drawing a region when playback. It is very useful when an emergency occurs. Perfect Image QualityHigh performance chip provides perfect image quality with better color reproduction. P2PMonitor at anytime and anywhere. Easily and conveniently mange the device. |
DVR Connection Diagram
HD video signals transfer over coax cables to the DVR (Digital Video Recorder). HD Camera are powered by plugging in the power supply. The DVR then converts the analog signal to digital, compresses it then stores it on a Hard Disk. The information is built into the DVR to handle scheduling, motion detection and digital zooming. To view the footage, monitors are connected to the DVR or you could use an internal network for viewing on PCs. DVR's can also be set up to broadcast over the internet and set up to be password protected. The video for all of the cameras are transmitted as one stream, one IP address.
What is our after-sale service System?
We offer 100% guarantee on our product after sales service. We provide one year service warranty free and we provide life time service just for service fee.
What is the price of DAHUA XVR5108HS-X in Bangladesh?
The latest price of DAHUA DAHUA XVR5108HS-X in Bangladesh is 9,500 ৳. You can buy the DAHUA DAHUA XVR5108HS-X at best price from our website or visit any of our showrooms.
We Provide Solution of Surveillance System in BD. |
|
|
|
We successfully installed Survillance System to Many Banks and corporate in Bangladesh, some of the projects are: |
||
Banks |
Corporates |
|
…Other many more Projects |
…Other many more Projects |
|
