Hikvision DS-7204HUHI-F2 4CH Turbo HD DVR
Hikvision HIK-7204HUHI-F2 3MP Turbo HD DVR
H.264 ,H.264+& Dual-stream video compression
Support HD-TVI 3MP, IPC,AHD and analog cameras with adaptive access
Support Cloud storage(One Drive, Google Drive or Drop Box)
HDMI and VGA output at up to 1920×1080P resolution,
Long transmission distance over coax cable
Up to 4/8-ch synchronous playback at 1080p resolution
Playback at up to 256X speed.
Hikvision DS-7204HUHI-F2 4CH Turbo HD DVR
The Hikvision DS-7204HUHI-F2 4-Channel Turbo HD DVR is a high-performance digital video recorder that delivers reliable HD surveillance and flexible recording options. Supporting up to 4 analog HD cameras (1080p) and additional IP inputs, it provides crystal-clear recording and smooth remote playback for both residential and commercial users.
Powered by Hikvision’s Turbo HD technology, this DVR allows you to upgrade your existing analog system to high-definition quality without replacing old cabling. Featuring H.264 + compression, HDMI/VGA output, and mobile remote access, the DS-7204HUHI-F2 offers efficient storage, superior image clarity and 24/7 security monitoring.
Features and Functions
Video Input and Transmission
- Connectable to HDTVI, AHD and analog cameras
- Up to 2-ch 4 MP IP cameras input
- Long distance transmission over UTP and coaxial cable with max. 1200m for the 720p and max. 800m for the 1080p HDTVI signal
Compression and Recording
- One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
- Full channel recording at up to 3MP resolution
Video Output
- Simultaneous HDMI/VGA output at up to 1920 × 1080 resolution for DS-7204HUHI-F2/N and 4K (3840 × 2160) resolution for HDMI output of DS-7208/7216HUHI-F2/N
- Independent CVBS output improves compatibility and serves as the aux output or live view output only for connection to RCA type monitors
Storage and Playback
- Two SATA interfaces (up to 6 TB capacity per HDD)
- 4/8/16-ch synchronous playback
- Smart search for efficient playback
Smart Function
- Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
- Supports line crossing detection and intrusion detection of all channels
- VQD (Video Quality Diagnostics)
- Unlock pattern for device login for the admin and clear-text password available
Network & Ethernet Access
- Hik Cloud P2P & HiDDNS (Dynamic Domain Name System) for easy network management
- One gigabit Ethernet network interface ( for DS-7208/7216HUHI-F2/N)
- Output bandwidth limit configurable
Technical Specifications:
| Specification Category | Details |
|---|---|
| Video Input – Analog | 4 channels, BNC interface (1.0 Vp-p, 75 Ω) for HD-TVI/AHD/CVI/CVBS video input. |
| Video Input – HD- TVI/AHD/CVI | Supports HD-TVI input up to 8 MP (3840 × 2160) @ lower frame-rates; AHD up to 5 MP, CVI up to 4 MP. |
| IP Video Input | Supports additional IP camera channels (commonly 2 extra channels of IP up to 4 MP each) in many variants. |
| Compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 video compression supported. |
| Encoding Resolution / Frame Rates | Main stream examples: 8 MP @ 8 fps, 5 MP @ 12 fps, 4 MP @ 15 fps, 3 MP @ 18 fps; 1080p/720p @ 25/30fps. Sub-stream: WD1/4CIF/CIF @ 25/30fps. |
| Video Bit-Rate | 32 Kbps to 10 Mbps approximate range for bit-rate configuration. |
| Output (Video/Monitor) | HDMI and VGA outputs: e.g., HDMI up to 2K (2560×1440) @ 60Hz in some variants. |
| Storage Interface & Capacity | 1 SATA interface (in many variants) supporting HDDs up to 10 TB (in each disk) depending on model. |
| Network Interface | 1 × RJ-45 10 Mb/100 Mb self-adaptive Ethernet port. Supports protocols such as TCP/IP, DHCP, Hik- Connect, DDNS, UPnP, ONVIF. |
| Alarm & I/O | Alarm input/output example: 4 in / 1 out in many variants. USB interface: 2 × USB 2.0. RS-485 serial i nterface. |
| Power Supply | Typically 12 V DC (varies by region). |
| Operating Environment | Temperature: –10 °C to +55 °C (14 °F to 131 °F), Humidity: 10% to 90%. |
| Dimensions & Weight | Example: 315 × 242 × 45 mm (12.4″ × 9.5″ × 1.8″) for certain models; weight (without HDD) ≤ 1.16 kg – 1.5 kg depending. |
| Power Consumption | Without HDD: e.g., ≤10 W in some variants. |
