Dahua XVR1A08 8 Channel Penta-brid XVR
Dahua XVR1A08 8-Channel Penta-brid XVR
Model: Dahua XVR1A08 8-Channel Penta-brid XVR
Video Input: 8 analog BNC channels + 2 IP channels (8+2)
Supported Formats: HDCVI, AHD, TVI, CVBS, IP camera inputs
Video Output: HDMI ×1, VGA ×1
Display Resolutions: 1920×1080, 1280×1024, 1280×720
Compression: H.264 encoding
Incoming Bandwidth: Up to ~40 Mbps
Storage: 1 SATA port, up to 6 TB HDD
Dahua XVR1A08 8-Channel Penta-brid XVR
The Dahua XVR1A08 8-Channel Penta-brid XVR is a versatile, future-ready video recorder tailored for Bangladesh’s CCTV installations. It supports five video formats (HDCVI/AHD/TVI/CVBS/IP), offers long-distance coax transmission, one SATA HDD up to 6 TB, and incoming bandwidth up to 40 Mbps — ideal for home, retail or small-to-medium business security systems.
Key Features
-
Supports 8 analog channels + IP extension (up to 8+2 channels), each IP channel up to 5 MP resolution.
-
Compatible with HDCVI, AHD, TVI, CVBS and IP camera inputs — true “penta-brid” flexibility.
-
Long-distance coaxial cable transmission capability, simplifying upgrades from analog systems.
-
Single SATA HDD slot supporting up to 6 TB storage — ideal for extended recording retention.
-
HDMI and VGA simultaneous video output supporting resolutions up to 1920×1080, 1280×1024, 1280×720, 1024×768.
-
Network features include 100M RJ-45 interface, ONVIF support, remote access via iPhone/Android.
-
Compact 1U form factor (197 mm × 192 mm × 41 mm) and low power consumption (<10 W) for efficient setups.
