HIKVISION DS-2CD2232-I5 3MP EXIR Bullet Network CCTV Camera
HIKVISION DS-2CD2232-I5 3MP CCTV Security Camera Gives you HD quality video compression, remote internet viewing, motion detection,night-vision also, it is smartphone compatible (IPhone, Android & Blackberry) as well as viewable over the internet network using IE browser (no app necessary).The camera functions well as part of a home or office security system with remote internet monitoring ability.
Hikvision 3 megapixel high-resolution CCTV Security Camera adopts a best HD video quality 3MP high-resolution real-time video as well as a 2048×1536 high-speed video protocol processor. As a result, it is capable of H.264/MJPEG video compression allowing for extremely smooth video transmission with minimal bandwidth consumption. Also, due to the small file sizes produced by H.264/MJPEG video compression, it can save tremendous hard drive space when doing video recording.
Brand : HIKVISION
Model : DS-2CD2232-I5
FEATURES:
3-megapixel high resolution
Low illumination
3D DNR & DWDR & BLC
IP66 rating
IR range: up to 50m
True day / night
|
Camera |
|
|
Image Sensor: |
1/3" Progressive Scan CMOS |
|
Min. Illumination: |
0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR |
|
Shutter time: |
1/3 s to 1/100,000 s |
|
Lens: |
4mm@ F2.0 (6mm, 12mm optional) |
|
Lens Mount: |
M12 |
|
Day& Night: |
IR cut filter with auto switch |
|
Wide Dynamic Range: |
Digital WDR |
|
Digital noise reduction: |
3D DNR |
|
Compression Standard |
|
|
Video Compression: |
H.264/MJPEG |
|
Video bit rate: |
32Kbps~12Mbps |
|
Dual Stream: |
Yes |
|
Image |
|
|
Max. Image Resolution: |
2048×1536 |
|
Frame Rate: |
50Hz: 20fps (2048 × 1536), 25fps (1920 × 1080), 25fps (1280 × 720) |
|
Image Settings: |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
|
BLC: |
Yes, zone configurable |
|
ROI: |
Support |
|
Network |
|
|
Network Storage: |
NAS (Support NFS,SMB/CIFS) |
|
Alarm Trigger: |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
|
Protocols: |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, |
|
General Function: |
User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask |
|
System Compatibility: |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
|
Interface |
|
|
Communication Interface: |
1 RJ45 10M / 100M Ethernet interface |
|
General |
|
|
Operating Conditions: |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) |
|
Power Supply: |
12 VDC ± 10%, PoE (802.3af) |
|
Power Consumption: |
Max. 7 W (Max. 9 W with IR cut filter on) |
|
Weather Proof: |
IP66 |
|
IR Range: |
Up to 50m |
|
Dimensions: |
105×104.8×263.1mm (4.13” × 4.13” × 10.38”) |
|
Weight: |
950g (2.09 lbs) |
Warranty:
Limited Warranty for IP CCTV Security Video Surveillance Products from Germany Computer And Telecom Limited . Our After Sales Support policies provides you the minimum 1-year warranty on all products.
