ETD-100 Portable Explosive Detector

The ETD-100 is a field-portable, laboratory-grade detection system that identifies inorganic salt-based explosives (nitrates, chlorates, perchlorates) in under 60 seconds. With intuitive touchscreen and ultra-low detection limits, it brings the lab to the checkpoint.

Key Features

Detects inorganic salt-based explosives (nitrates, chlorates, perchlorates) – the primary threat in homemade IEDs.
Rapid analysis – delivers results in less than one minute.
Portable and robust – designed for both mobile and stationary deployments such as checkpoints, border control and forensic labs.
Simple user interface – touchscreen operation with “red/green” alarm screens and audible alerts, minimal training required.
Non-radioactive technology – uses liquid phase Capillary Zone Electrophoresis (CZE) rather than ion mobility with radioactive source.
Low operational cost – minimal consumables (reagent cartridge, swabs, filters), automatic self-calibration and high throughput.
Network enabled – Ethernet, Wi-Fi and USB connectivity for data export and remote access.

Technical Specifications

Specification	Details
Detection technology	Capillary Zone Electrophoresis (CZE) – liquid phase, non-radioactive
Explosive types detected	Nitrates, chlorates and perchlorates (inorganic salt-based explosives)
Limit of detection	Approx. 20-60 ng depending on ion (typical)
Analysis time	Less than 1 minute (typical ~40–60 s)
Start-up / warm-up time	Typically 10-15 minutes
Dimensions (W × D × H)	48.8 × 38.6 × 22.9 cm (19.20″ × 15.20″ × 9.00″)
Weight	14.5 kg (32.0 lbs) without reagent cartridge
Operating temperature	+5 °C to +40 °C (40°F to 104°F)
Power supply	AC 100-240 V, 50-60 Hz; DC 24 V DC, 3.75 A max
Connectivity	Ethernet, Wi-Fi, USB 2.0
Reagent cartridge capacity	Approximately 1,500 scans (typical)
IP rating	IP63 when closed in Pelican case
