TOA TS-911 Chairman Unit for Conference System

The TOA TS-911 Chairman Unit is the flagship chairperson station in the TS-910 wired conference system lineup, designed to empower meeting leaders with full control, priority speech access, multilingual channel selection, built-in voting keys and seamless integration into corporate, government or international conference environments.

Featuring a compact, sturdy design, the TS-911 connects directly to the TS-919 Bridge Unit (for single- or multi-conference configurations) and uses the TS-910 Central Unit (via TS-918 Expansion) to support large scale assemblies. With a built-in loudspeaker, dual headphone jacks, priority speech key, voting buttons and recording output, this chairman unit offers both high functionality and professional presentation.

Perfect for boardrooms, council chambers, training rooms or multi-language convention halls, the TS-911 ensures the chairperson’s voice takes precedence, the meeting runs smoothly, and multilingual attendees stay engaged.

Techical Specifications:

Power Source	24 V DC (supplied from the TS-918 Expansion Unit (option))
Current Consumption	Max. 60 mA
Modulation Method	Frequency modulation
Carrier Frequency	Transmission: Audio channel 1: 7.35 MHz Audio channel 2: 8.10 MHz Audio channel 3: 8.55 MHz Audio channel 4: 9.15 MHz Control channel: 6.45 MHz Reception: Base language channel: 1.95 MHz Translation language channel: 2.25 MHz
Input	Microphone terminal: XLR-4-31 type (dedicated for connecting the optional TS-903 or TS-904)
Output	Monitor speaker: 8 Ω, 0.2 W Headphone: φ3.5 mm mini Jack (3P:monaural) × 2
Connection Terminal	RJ45 connector
LED Indicator	Speech indicator (flashes at communication failure), Voting status indicators 1 -3, Power indicator (flashes at communication failure)
Function	Monitor volume control, Headphone volume control, Priority speech function, Voting function, Monitor selector switch (MAIN/SUB)
Operating Temperature	0 ℃ to +40 ℃ (32 ゜F to 104 ゜F)
Operating Humidity	90 %RH or less (no condensation)
Finish	Top panel: ABS resin, gray metallic, paint, semi-gloss
Dimensions	210 (W) × 68.6 (H) × 152 (D) mm (8.27" × 2.7" × 5.98")
Weight	570 g (1.26 lb)
Option	Microphone: TS-903, TS-904 (Select either one.)
