VARITO VXR3G-6550D X Ray Baggage Scanner
VARITO VXR3G-6550D X Ray Baggage Scanner
Model: VXR3G-6550D
Tunnel Size (W × H): Approx. 660 mm × 510 mm
Conveyor Belt Speed: Approx. 0.22 m/s
Conveyor Belt Height: Approx. 690 mm from floor level
Max. Penetration: Up to approx. 32 mm steel plate
X Ray Generator: Approx. 80–160 kV
X Ray Beam: Multi-view Scanning
Spatial Resolution: Horizontal: ~1.0 mm / Vertical: ~1.0 mm
Line Resolution: AWG40 (≈0.0787 mm wire)
Display Resolution: 1920 × 1080, 24-bit color
Monitor Type: Dual 21.5" LCD color monitors
VARITO VXR3G-6550D X Ray Baggage Scanner
VARITO VXR3G-6550D X Ray Baggage Scanner is a professional 6550 tunnel security scanner designed for airports, bus terminals, railway stations, offices and commercial buildings in Bangladesh. With a 660 × 510 mm conveyor opening, fast 0.22 m/s belt speed and up to 32 mm steel penetration, it delivers clear multi-view images for reliable detection of weapons, explosives and contraband. Advanced 3-color imaging, low radiation leakage and stainless steel construction make it ideal for 24/7 high-traffic security checkpoints.
Germany Computer is the only authorized distributor of VARITO Brand X Ray Baggage Scanner in Bangladesh, supplying 100% genuine security screening machines with full warranty and technical support. The VARITO VXR3G-6550D Baggage Scanner price in Bangladesh starts from ৳7,50,000 up to ৳50,00,000, depending on model, tunnel size and project requirements.
Key Features
-
VXR3G-6550D class X Ray baggage scanner for luggage, parcels and cargo screening
-
Stainless steel heavy-duty body for long-term industrial and transport use
-
660(W) × 510(H) mm tunnel size – suitable for medium and large bags
-
High penetration up to approx. 32 mm steel for dense object inspection
-
Adjustable X Ray source (approx. 80–160 kV) for clear material differentiation
-
3-color imaging to distinguish organic, inorganic and mixed materials at a glance
-
Dual 21.5" LCD operator monitors with Full HD display for detailed analysis
-
Fast conveyor speed around 0.22 m/s for high throughput at busy checkpoints
-
Low radiation leakage (below common international limits) for safe daily operation
-
Suitable for airports, metro and train stations, government offices, prisons, schools and large commercial facilities
Technical Specifications
|
Parameter |
Specification |
|
Model |
VXR3G-6550D |
|
Tunnel Size (W × H) |
Approx. 660 mm × 510 mm |
|
Conveyor Belt Speed |
Approx. 0.22 m/s (continuous operation) |
|
Conveyor Belt Height |
Approx. 690 mm from floor level |
|
Max. Penetration |
Up to approx. 32 mm steel plate |
|
X Ray Generator |
Approx. 80–160 kV, 0.5–1.25 mA (sealed X Ray tube) |
|
X Ray Beam |
Multi-view scanning configuration |
|
Spatial Resolution |
Horizontal: ~1.0 mm / Vertical: ~1.0 mm |
|
Line Resolution |
AWG40 (≈0.0787 mm wire) |
|
Display Resolution |
1920 × 1080, 24-bit color |
|
Monitor Type |
Dual 21.5" LCD color monitors, operator console |
|
Imaging Mode |
3-color imaging (organic / inorganic / mixed materials) |
|
Material Display |
Organics in orange, inorganics in blue, mixed materials in green |
|
Memory / Storage |
4 GB RAM, 256 GB SSD (typical factory configuration) |
|
Power Supply |
AC 220 V, 50 Hz |
|
Power Consumption |
Approx. 1000 W |
|
Equipment Dimensions (L × W × H) |
Approx. 2140 mm × 1335 mm × 1365 mm |
|
Equipment Weight |
Approx. 480 kg |
|
Radiation Leakage |
< 0.5 μSv/h at 50 mm from housing (within international safety limits) |
|
Single Scan Dose |
< 5 μGy (typical) |
|
Operating Temperature |
Approx. 5 °C to 40 °C |
|
Relative Humidity |
Up to 95% (non-condensing) |
|
Construction Material |
Stainless steel cabinet, heavy-duty frame |
|
Certificates |
CE, ISO, FCC (based on original platform certification) |
| Call for Price | No |
|---|---|
| Brand | Varito |
