P8 Outdoor LED Display Module 320×320mm
P8 Outdoor LED Display Module 320×320mm
Pixel Pitch: 8.0 mm
LED Type: RGB 3-in-1 DIP
Module Size: 320 × 320 mm
Module Resolution: 40 (H) × 40 (V) pixels
Pixel Density: 15,625 pixels/m²
Brightness (White): ≈ 10,000 nits
Best Viewing Distance: ≥ 8 m
Viewing Angle (H/V): ~140° / ~120°
P8 Outdoor LED Display Module 320×320mm
The P8 Outdoor LED Display Module features an 8 mm pixel pitch with full-colour RGB 3-in-1 DIP LEDs in a rugged 320 × 320 mm panel size. Built for outdoor signage and large-scale video walls, it delivers high brightness, wide viewing angles and weather-proof durability.
Key Features
-
8 mm pixel pitch (P8) for optimal outdoor viewing clarity at moderate to long distances
-
RGB 3-in-1 DIP LED package, integrating red, green and blue chips in a single LED for rich colour reproduction and uniform brightness.
-
Module size: 320 × 320 mm with resolution 40 × 40 pixels; compatible with standard outdoor cabinets and supports front-access maintenance.
-
High brightness (≈ 10,000 nits typical) and suitable for sunlight-facing environments.
-
Wide viewing angle (~140° horizontal / ~120° vertical) for broad audience visibility.
-
Constant-current driving, 1/4 scan driver mode, CE/RoHS certified, 2-year warranty.
-
Outdoor-rated waterproof protection (IP65) for reliable performance in harsh environments.
Technical Specification:
|
Specification |
Value |
|
Pixel Pitch |
8.0 mm |
|
LED Type / Package |
RGB 3-in-1 DIP |
|
Module Size |
320 × 320 mm |
|
Module Resolution |
40 (H) × 40 (V) pixels |
|
Pixel Density |
15,625 pixels/m² |
|
Brightness (White) |
≈ 10,000 nits |
|
Best Viewing Distance |
≥ 8 m |
|
Viewing Angle (H/V) |
~140° / ~120° |
|
Driving Mode / Scan |
1/4 scan |
|
Average Power Consumption |
~230 W/m² |
|
Max Power Consumption |
~700 W/m² |
|
Operating Temperature |
-20 °C to +50 °C |
|
Protection Grade |
IP65 (front) |
|
Lifetime |
≥ 100,000 hours |
|
Warranty Time |
2 years |
| Call for Price | No |
|---|---|
| Brand | Varito |
