P3.91 Outdoor LED Display Module
P3.91 Outdoor LED Display Module
Pixel Pitch: 3.91 mm
LED Arrangement: SMD1921
Module Size: 250 mm × 250 mm
Resolution (H×V): 64 × 64 pixels
Brightness: 5,500 - 6,000 cd/m² (typical)
Best Viewing Distance: ~4 m to ~40 m
Viewing Angle: ~140° horizontal / ~140° vertical
Grey Scale / Color Depth: 8-bit input with correction up to 16-bit; 16.7 M colors
P3.91 Outdoor LED Display Module
This P3.91mm outdoor LED module from UNIT LED is designed for demanding outdoor signage and rental LED walls in Bangladesh. With a pixel pitch of 3.91mm and module size of 250×250 mm (64×64 pixels), it delivers high clarity from 4 m and beyond. Built for durability, it uses SMD1921 LED chips, offers IP65 protection and supports harsh weather and high-brightness outdoor environments.
Key Features:
-
Pixel pitch: 3.91 mm, ideal for outdoor viewing distances of ~4-40 m.
-
Module size: 250 mm × 250 mm with resolution 64 (H) × 64 (V) pixels.
-
LED arrangement: SMD1921 high quality for uniform brightness and durability.
-
Brightness: Typically 5,500-6,000 cd/m² for daylight-readable outdoor visibility.
-
Viewing angle: Wide horizontal/vertical (~140°/140°) giving good audience coverage.
-
Waterproof & outdoor-proof: Protection level IP65, suitable for Bangladesh outdoor conditions (rain, sun, high humidity).
-
Operating range: Works at temperatures from approx. –20 °C to +60 °C, humidity 10-95% RH.
-
High refresh & contrast: Refresh rate up to 960-1920Hz for flicker-free visuals (especially for camera-captured usage).
-
Reliable product from a manufacturer with ageing test and warranty support, important for local installations in Bangladesh.
Technical Specifications:
|
Parameter |
Specification |
|
Model |
P3.91-Outdoor-64×64 |
|
Pixel Pitch |
3.91 mm |
|
LED Arrangement |
SMD1921 |
|
Module Size |
250 mm × 250 mm |
|
Resolution (H×V) |
64 × 64 pixels |
|
Brightness |
5,500 - 6,000 cd/m² (typical) |
|
Best Viewing Distance |
~4 m to ~40 m |
|
Viewing Angle |
~140° horizontal / ~140° vertical |
|
Grey Scale / Colour Depth |
8-bit input with correction up to 16-bit; 16.7 M colours |
|
Brightness Adjustment |
100 levels |
|
Power Supply |
AC 100-240 V, 50/60Hz |
|
Max Power Consumption |
~950 W/m² (typical spec) |
|
Average Power Consumption |
~320 W/m² (typical spec) |
|
Refresh Rate |
960-1920Hz |
|
Operating Temperature |
–20 °C to +60 °C |
|
Operating Humidity |
10% to 95% RH |
|
Protection Level |
IP65 |
|
Life Expectancy |
≥100,000 hours |
|
Pixel Failure Rate |
≤0.01% |
