P1.667 Flexible LED Module
P1.667 Flexible LED Module
Pixel Pitch: 1.667 mm
Module Size: 240 mm × 120 mm
Resolution (module): 144 × 72 pixels
LED Type / Package: SMD 1212
Brightness (White): Approx. 650-700 cd/m²
Refresh Rate: ≥ 3840 Hz
Scan Mode: 1/36 scan typical
P1.667 Flexible LED Module
The P1.667 mm Flexible LED Module offers an ultra-fine 1.667 mm pixel pitch combined with a soft-flexible substrate design, enabling high-definition indoor displays on curved, cylindrical or free-form surfaces. Ideal for premium retail environments, exhibition walls, architectural integration and creative LED installations where resolution and shape-adaptability matter.
Key Features:
-
Ultra-fine 1.667 mm pixel pitch delivers very high pixel density and clarity at close viewing distances.
-
Soft flexible module substrate allows bending into concave or convex curves, enabling creative shapes and non-flat installations.
-
Thin, lightweight module design (~8.6 mm thickness) makes installation easier and reduces structural load demands.
-
High refresh rate (≥ 3840 Hz) supports smooth video playback and camera-friendly environments.
-
High brightness (approx. 650-700 cd/m²) and wide viewing angles ensure vibrant indoor visual performance.
-
CE, RoHS, FCC approved, built for professional indoor fixed installations.
Technical Specification:
|
Parameter |
Specification |
|
Pixel Pitch |
|
|
Module Size |
|
|
Resolution (module) |
144 × 72 pixels |
|
LED Type / Package |
SMD 1212 (or SMD1010-1212 depending) |
|
Brightness (White) |
Approx. 650-700 cd/m² |
|
Refresh Rate |
≥ 3840 Hz |
|
Scan Mode |
1/36 scan typical |
|
Input Voltage |
DC 5V |
|
Max Power Consumption |
Approx. 16 W per module (as typical) |
|
Module Thickness |
~8.6 mm |
|
Certifications |
CE, RoHS, FCC |
| Call for Price | No |
|---|---|
| Brand | Varito |
